Building Scalable Message Queues with Redis Streams and Dynamic Consumers

Learn how to build a production-ready message queue system using Redis Streams that scales from 1 to N workers with guaranteed message isolation and zero coordination overhead.

What You'll Learn

By the end of this guide, you'll understand:

1. The Problem: How to handle multiple users sending messages to multiple AI services with guaranteed response isolation
2. The Solution: Shared input queues + per-user response streams architecture
3. Consumer Groups: How Redis automatically distributes work across workers
4. Dynamic Scaling: Adding and removing workers with zero configuration changes
5. Real Implementation: Complete working code with practical examples

The Problem: Message Routing at Scale

Imagine you're building an AI chatbot service. Here's the scenario:

• Alice sends "Hello AI!" to your service
• Bob sends "Hi there!" at the same time
• You have 3 AI workers processing messages
• Worker 1 picks up Alice's message
• Worker 2 picks up Bob's message
• Critical Question: How does Alice get only her response and not Bob's?

The Naive Approach (Don't Do This)

# Bad: Single queue with filtering
async def user_reads_responses(user_id):
    while True:
        messages = await redis.xread({"shared_responses": ">"})
        for msg in messages:
            # Filter through ALL messages to find yours
            if msg["user_id"] == user_id:
                return msg["response"]
            # Problem: Alice sees Bob's messages pass by
            # Problem: Multiple users competing for the same stream
            # Problem: No message isolation

Why this fails:

• No message isolation (users see each other's messages)
• Inefficient filtering on the client side
• Race conditions when multiple consumers read the same stream
• Messages might be processed multiple times

The Right Architecture

Multiple Users → Shared Input Queue → Multiple AI Workers → Per-User Streams → Correct User
      ↓                    ↓                      ↓                  ↓
   alice, bob      user_messages_queue    ai-worker-1,2,3    ai_to_user:alice
                                                             ai_to_user:bob

Key Insight: Separate the input aggregation from output distribution.

The Solution: Dual-Stream Architecture

Architecture Component 1: Shared Input Queue

# All users write to ONE shared stream
await redis.xadd(
    "user_messages_queue",
    {
        "user_id": "alice",
        "message": "Hello AI!",
        "timestamp": datetime.now().isoformat()
    }
)

Benefits:

• Natural work aggregation
• Any AI worker can handle any message
• Built-in load balancing via consumer groups
• No coordination between users needed

Architecture Component 2: Per-User Response Streams

# AI worker extracts user_id and writes to dedicated stream
user_id = message_data["user_id"]
await redis.xadd(
    f"ai_to_user:{user_id}",  # alice gets ai_to_user:alice
    {
        "response": "Echo: Hello AI!",
        "timestamp": datetime.now().isoformat()
    }
)

Benefits:

• Complete isolation - Alice never sees Bob's responses
• No filtering logic needed
• Each user subscribes only to their stream
• Works with any number of AI workers

The Magic: Consumer Groups

Consumer groups are Redis's built-in mechanism for distributing messages across multiple workers:

# Create consumer group (done once)
await redis.xgroup_create(
    "user_messages_queue",
    "ai_service_group",
    id='0',
    mkstream=True
)

# Multiple workers read from the same group
messages = await redis.xreadgroup(
    group_name="ai_service_group",
    consumer_name="ai-worker-1",  # Each worker has unique name
    streams={"user_messages_queue": ">"},  # '>' = only new messages
    count=1,
    block=5000
)

What Redis Guarantees:

• Each message delivered to exactly one worker in the group
• Automatic load balancing across all workers
• Message acknowledgment for reliability
• Pending message tracking for failure recovery

Complete Implementation

Let's build a complete working system. You can find the full code here: github.com/rakeshbhugra/dynamic_consumers_for_redis_streams

Project Structure

src/
├── user_simulate.py    # User class (produces + consumes)
├── user1.py            # Alice implementation
├── user2.py            # Bob implementation
├── ai_service.py       # AI worker implementation
└── stream_info.py      # Real-time monitoring

Step 1: User Implementation

The User class handles both sending messages and receiving responses:

# user_simulate.py
import asyncio
from redis.asyncio import Redis

class User:
    def __init__(self, user_id: str, redis_url: str = "redis://localhost:6379"):
        self.user_id = user_id
        self.redis_url = redis_url
        self.input_queue = "user_messages_queue"
        self.response_stream = f"ai_to_user:{user_id}"

    async def setup(self):
        """Initialize Redis connection and consumer group"""
        self.redis = Redis.from_url(self.redis_url, decode_responses=True)

        # Create consumer group for this user's response stream
        try:
            await self.redis.xgroup_create(
                self.response_stream,
                f"wsgroup_{self.user_id}",
                id='0',
                mkstream=True
            )
        except Exception as e:
            if "BUSYGROUP" not in str(e):
                raise

    async def send_message(self, message: str):
        """Send message to shared input queue"""
        message_id = await self.redis.xadd(
            self.input_queue,
            {
                "user_id": self.user_id,
                "message": message,
                "timestamp": datetime.now().isoformat()
            }
        )
        print(f"[{self.user_id}] Sent: {message}")
        return message_id

    async def receive_responses(self):
        """Listen for responses on dedicated stream"""
        consumer_name = f"consumer_{self.user_id}"

        while True:
            try:
                # Read from consumer group
                messages = await self.redis.xreadgroup(
                    f"wsgroup_{self.user_id}",
                    consumer_name,
                    {self.response_stream: ">"},
                    count=1,
                    block=5000
                )

                if messages:
                    for stream, message_list in messages:
                        for message_id, data in message_list:
                            response = data.get("response")
                            print(f"[{self.user_id}] Received: {response}")

                            # Acknowledge message
                            await self.redis.xack(
                                self.response_stream,
                                f"wsgroup_{self.user_id}",
                                message_id
                            )

            except Exception as e:
                print(f"[{self.user_id}] Error: {e}")
                await asyncio.sleep(1)

    async def run(self, messages: list):
        """Run user simulation: send messages and listen for responses"""
        await self.setup()

        # Start response listener in background
        listener_task = asyncio.create_task(self.receive_responses())

        # Send messages with delay
        for msg in messages:
            await self.send_message(msg)
            await asyncio.sleep(2)

        # Keep listening for responses
        await listener_task

Step 2: AI Service Implementation

The AI service consumes from the shared queue and routes responses:

# ai_service.py
import asyncio
import sys
from redis.asyncio import Redis
from datetime import datetime

class AIService:
    def __init__(self, worker_id: str, redis_url: str = "redis://localhost:6379"):
        self.worker_id = worker_id
        self.redis_url = redis_url
        self.input_queue = "user_messages_queue"
        self.consumer_group = "ai_service_group"

    async def setup(self):
        """Initialize Redis and create consumer group"""
        self.redis = Redis.from_url(self.redis_url, decode_responses=True)

        try:
            await self.redis.xgroup_create(
                self.input_queue,
                self.consumer_group,
                id='0',
                mkstream=True
            )
            print(f"[{self.worker_id}] Created consumer group")
        except Exception as e:
            if "BUSYGROUP" in str(e):
                print(f"[{self.worker_id}] Consumer group already exists")
            else:
                raise

    async def process_message(self, user_id: str, message: str):
        """Process user message (simulate AI processing)"""
        # Simulate processing time
        await asyncio.sleep(1)

        # Echo the message back (replace with actual AI logic)
        response = f"Echo: {message}"

        return response

    async def start(self):
        """Start consuming messages from the queue"""
        await self.setup()
        print(f"[{self.worker_id}] Started consuming messages...")

        while True:
            try:
                # Read messages from consumer group
                messages = await self.redis.xreadgroup(
                    self.consumer_group,
                    self.worker_id,
                    {self.input_queue: ">"},
                    count=1,
                    block=5000
                )

                if messages:
                    for stream, message_list in messages:
                        for message_id, data in message_list:
                            user_id = data.get("user_id")
                            message = data.get("message")

                            print(f"[{self.worker_id}] Processing message from {user_id}: {message}")

                            # Process the message
                            response = await self.process_message(user_id, message)

                            # Send response to user-specific stream
                            response_stream = f"ai_to_user:{user_id}"
                            await self.redis.xadd(
                                response_stream,
                                {
                                    "response": response,
                                    "worker_id": self.worker_id,
                                    "timestamp": datetime.now().isoformat()
                                }
                            )

                            print(f"[{self.worker_id}] Sent response to {user_id}")

                            # Acknowledge message processing
                            await self.redis.xack(
                                self.input_queue,
                                self.consumer_group,
                                message_id
                            )

            except Exception as e:
                print(f"[{self.worker_id}] Error: {e}")
                await asyncio.sleep(1)


async def main():
    worker_id = sys.argv[1] if len(sys.argv) > 1 else "ai-worker-1"
    service = AIService(worker_id)
    await service.start()

if __name__ == "__main__":
    asyncio.run(main())

Step 3: User Instances

# user1.py
import asyncio
from user_simulate import User

async def main():
    alice = User("alice")
    messages = [
        "Hello AI!",
        "How are you?",
        "Tell me a joke"
    ]
    await alice.run(messages)

if __name__ == "__main__":
    asyncio.run(main())


# user2.py
import asyncio
from user_simulate import User

async def main():
    bob = User("bob")
    messages = [
        "Hi there!",
        "What's the weather?",
        "Tell me a story"
    ]
    await bob.run(messages)

if __name__ == "__main__":
    asyncio.run(main())

Step 4: Stream Monitoring

Monitor all streams in real-time:

# stream_info.py
import asyncio
from redis.asyncio import Redis

STREAMS_TO_MONITOR = [
    "user_messages_queue",
    "ai_to_user:alice",
    "ai_to_user:bob"
]

CONSUMER_GROUPS = {
    "user_messages_queue": "ai_service_group",
    "ai_to_user:alice": "wsgroup_alice",
    "ai_to_user:bob": "wsgroup_bob"
}

async def monitor_streams():
    redis = Redis.from_url("redis://localhost:6379", decode_responses=True)

    while True:
        print("\n" + "="*80)
        print("REDIS STREAMS MONITORING")
        print("="*80)

        for stream in STREAMS_TO_MONITOR:
            try:
                # Get stream length
                length = await redis.xlen(stream)
                print(f"\n📊 Stream: {stream}")
                print(f"   Length: {length} messages")

                # Get consumer group info
                if stream in CONSUMER_GROUPS:
                    group = CONSUMER_GROUPS[stream]
                    try:
                        groups = await redis.xinfo_groups(stream)
                        for g in groups:
                            if g['name'] == group:
                                print(f"   Group: {group}")
                                print(f"   Pending: {g['pending']} messages")
                                print(f"   Consumers: {g['consumers']}")

                        # Get consumer details
                        consumers = await redis.xinfo_consumers(stream, group)
                        for c in consumers:
                            print(f"      - {c['name']}: idle {c['idle']}ms")
                    except Exception as e:
                        if "no such key" not in str(e).lower():
                            print(f"   Group info unavailable: {e}")

            except Exception as e:
                print(f"   Error: {e}")

        await asyncio.sleep(1)

if __name__ == "__main__":
    asyncio.run(monitor_streams())

Running the Complete System

Prerequisites

# Start Redis
docker-compose up -d

# Install dependencies
uv sync

Terminal Setup

Open 4 terminals and run:

Terminal 1: Stream Monitor

uv run src/stream_info.py

Terminal 2: AI Service

uv run src/ai_service.py ai-worker-1

Terminal 3: Alice

uv run src/user1.py

Terminal 4: Bob

uv run src/user2.py

What You'll See

Monitor Output:

================================================================================
REDIS STREAMS MONITORING
================================================================================

📊 Stream: user_messages_queue
   Length: 0 messages
   Group: ai_service_group
   Pending: 0 messages
   Consumers: 1
      - ai-worker-1: idle 234ms

📊 Stream: ai_to_user:alice
   Length: 2 messages
   Group: wsgroup_alice
   Pending: 0 messages
   Consumers: 1
      - consumer_alice: idle 156ms

📊 Stream: ai_to_user:bob
   Length: 1 messages
   Group: wsgroup_bob
   Pending: 0 messages
   Consumers: 1
      - consumer_bob: idle 189ms

AI Worker Output:

[ai-worker-1] Started consuming messages...
[ai-worker-1] Processing message from alice: Hello AI!
[ai-worker-1] Sent response to alice
[ai-worker-1] Processing message from bob: Hi there!
[ai-worker-1] Sent response to bob

Alice's Output:

[alice] Sent: Hello AI!
[alice] Received: Echo: Hello AI!
[alice] Sent: How are you?
[alice] Received: Echo: How are you?

Bob's Output:

[bob] Sent: Hi there!
[bob] Received: Echo: Hi there!
[bob] Sent: What's the weather?
[bob] Received: Echo: What's the weather?

Notice:

• Alice only sees her responses
• Bob only sees his responses
• Messages are processed by the AI worker
• Complete isolation despite shared infrastructure

Dynamic Scaling: Adding More Workers

One of the most powerful features is dynamic scaling. Let's add more AI workers:

Add Second Worker

Open Terminal 5:

uv run src/ai_service.py ai-worker-2

What Happens:

• Worker 2 joins the

  ai_service_group

• Redis automatically distributes messages between workers
• Worker 1 might process Alice's message
• Worker 2 might process Bob's message
• No configuration changes needed
• No coordination required

Monitor Output with 2 Workers:

📊 Stream: user_messages_queue
   Group: ai_service_group
   Consumers: 2
      - ai-worker-1: idle 123ms
      - ai-worker-2: idle 98ms

Add Third Worker

Open Terminal 6:

uv run src/ai_service.py ai-worker-3

Now you have 3 workers competing for messages. Redis distributes the load automatically.

Load Distribution Example

With 3 workers processing 9 messages:

[ai-worker-1] Processing: alice - "Hello AI!"
[ai-worker-2] Processing: bob - "Hi there!"
[ai-worker-3] Processing: alice - "How are you?"
[ai-worker-1] Processing: bob - "What's the weather?"
[ai-worker-2] Processing: alice - "Tell me a joke"
[ai-worker-3] Processing: bob - "Tell me a story"

Key observations:

• Messages distributed roughly evenly
• Each worker processes different users' messages
• Alice and Bob still get only their responses
• No worker conflicts or coordination needed

Advanced: Adding More Users

Create User 3

# user3.py
import asyncio
from user_simulate import User

async def main():
    charlie = User("charlie")
    messages = [
        "Hey everyone!",
        "What's going on?",
        "Anyone there?"
    ]
    await charlie.run(messages)

if __name__ == "__main__":
    asyncio.run(main())

Update Monitoring

# stream_info.py - add charlie
STREAMS_TO_MONITOR = [
    "user_messages_queue",
    "ai_to_user:alice",
    "ai_to_user:bob",
    "ai_to_user:charlie"  # Add new user
]

CONSUMER_GROUPS = {
    "user_messages_queue": "ai_service_group",
    "ai_to_user:alice": "wsgroup_alice",
    "ai_to_user:bob": "wsgroup_bob",
    "ai_to_user:charlie": "wsgroup_charlie"  # Add new user
}

Run Charlie

# Terminal 7
uv run src/user3.py

Charlie's messages automatically:

• Go to the shared queue
• Get processed by any available worker
• Responses go to

  ai_to_user:charlie

• Charlie sees only his responses

No changes to AI workers needed!

Why This Architecture Works

1. Clear Separation of Concerns

Input Aggregation:  user_messages_queue
                    ↓
Work Distribution:  Consumer Group (ai_service_group)
                    ↓
Output Isolation:   Per-user streams (ai_to_user:{user_id})

2. Zero Coordination Overhead

• Workers don't need to know about each other
• Users don't need to know about workers
• Redis handles all coordination
• Add/remove workers anytime

3. Guaranteed Message Delivery

# Message acknowledgment ensures processing
await redis.xack(stream, group, message_id)

# Pending messages can be recovered
pending = await redis.xpending(stream, group)

# Claim messages from failed workers
await redis.xclaim(stream, group, consumer, min_idle_time, message_ids)

4. Built-in Observability

# Stream length
await redis.xlen(stream)

# Consumer group info
await redis.xinfo_groups(stream)

# Consumer details
await redis.xinfo_consumers(stream, group)

# Pending messages
await redis.xpending(stream, group)

Performance Characteristics

Throughput

With proper configuration, this architecture handles:

Bottlenecks:

• Message processing time (your AI logic)
• Network latency to Redis
• Redis instance limits (use Redis Cluster for more)

Memory Usage

# Prevent unbounded growth - trim old messages
await redis.xtrim(
    stream,
    maxlen=10000,      # Keep last 10k messages
    approximate=True    # More efficient
)

# Or trim by time (pseudo-code)
cutoff = datetime.now() - timedelta(hours=24)
# Delete messages older than 24 hours

Scaling Limits

Single Redis instance:

• ~1M messages/sec throughput
• Millions of streams
• Thousands of consumers
• Memory is the main limit

For more scale:

• Use Redis Cluster
• Shard by user_id
• Multiple input queues with routing

Real-World Applications

1. Multi-Tenant Chat Applications

# Each tenant has their own response stream
response_stream = f"ai_to_tenant:{tenant_id}:user:{user_id}"

# AI workers handle any tenant
# Responses automatically isolated

2. Task Processing Systems

# Jobs from multiple clients
await redis.xadd("jobs_queue", {
    "client_id": client_id,
    "job_type": "video_encoding",
    "video_url": url
})

# Results to client-specific streams
result_stream = f"results:{client_id}"

3. IoT Data Processing

# Sensor data from multiple devices
await redis.xadd("sensor_data", {
    "device_id": device_id,
    "temperature": temp,
    "humidity": humidity
})

# Alerts to device-specific streams
alert_stream = f"alerts:{device_id}"

4. Microservices Communication

# Request queue shared by all services
request_queue = "service_requests"

# Response streams per requesting service
response_stream = f"responses:{requesting_service_id}"

Production Considerations

Error Handling

async def robust_message_processing(self):
    max_retries = 3
    retry_count = 0

    while retry_count < max_retries:
        try:
            messages = await self.redis.xreadgroup(...)

            for stream, message_list in messages:
                for message_id, data in message_list:
                    try:
                        # Process message
                        await self.process_message(data)

                        # Acknowledge on success
                        await self.redis.xack(stream, group, message_id)
                        retry_count = 0  # Reset on success

                    except Exception as e:
                        log.error(f"Processing failed: {e}")
                        # Don't ack - message stays pending
                        retry_count += 1

        except Exception as e:
            log.error(f"Read failed: {e}")
            await asyncio.sleep(1)

Dead Letter Queue

async def handle_failed_messages(self):
    """Move repeatedly failed messages to dead letter queue"""

    pending = await redis.xpending_range(
        stream,
        group,
        min="-",
        max="+",
        count=100
    )

    for msg in pending:
        if msg["times_delivered"] > 5:
            # Move to dead letter queue
            await redis.xadd("dead_letter_queue", msg["data"])

            # Acknowledge to remove from pending
            await redis.xack(stream, group, msg["message_id"])

Monitoring and Alerts

async def monitor_queue_health(self):
    """Alert on queue health issues"""

    # Check pending messages
    groups = await redis.xinfo_groups(stream)
    for group_info in groups:
        pending = group_info["pending"]

        if pending > 1000:
            alert("High pending message count", pending)

    # Check consumer lag
    consumers = await redis.xinfo_consumers(stream, group)
    for consumer in consumers:
        idle_time = consumer["idle"]

        if idle_time > 60000:  # 1 minute
            alert(f"Consumer {consumer['name']} is idle")

    # Check stream growth
    length = await redis.xlen(stream)
    if length > 100000:
        alert("Stream growing unbounded", length)

Graceful Shutdown

class AIService:
    def __init__(self):
        self.should_stop = False

    async def start(self):
        # Handle shutdown signals
        loop = asyncio.get_event_loop()
        for sig in (signal.SIGTERM, signal.SIGINT):
            loop.add_signal_handler(
                sig,
                lambda: asyncio.create_task(self.shutdown())
            )

        while not self.should_stop:
            # Process messages
            await self.process_messages()

    async def shutdown(self):
        """Gracefully shutdown"""
        print("Shutting down...")
        self.should_stop = True

        # Finish processing current message
        # Don't claim new messages

        # Close Redis connection
        await self.redis.close()

        print("Shutdown complete")

Comparison with Other Solutions

vs RabbitMQ

Redis Streams Advantages:

• Simpler setup and operations
• Better performance for high-throughput scenarios
• Native support for multiple consumers per message
• More flexible message patterns

RabbitMQ Advantages:

• More advanced routing
• Better durability guarantees
• More mature ecosystem
• AMQP protocol support

vs Kafka

Redis Streams Advantages:

• Much simpler to set up and operate
• Lower latency
• Better for transient data
• Easier integration with existing Redis usage

Kafka Advantages:

• Better for long-term data retention
• More powerful partitioning
• Better for event sourcing
• Better for large-scale analytics

vs AWS SQS/SNS

Redis Streams Advantages:

• Lower latency (no API calls)
• More flexible patterns
• Better for real-time processing
• Can run anywhere (not cloud-locked)

SQS/SNS Advantages:

• Fully managed
• Better for async workflows
• Built-in dead letter queues
• Easier autoscaling integration

Decision Matrix

Use Redis Streams when:
✅ You need low latency (<10ms)
✅ You already use Redis
✅ You want simple operations
✅ Message data is transient
✅ You need flexible patterns

Use Kafka when:
✅ You need long-term retention
✅ You're doing event sourcing
✅ You need complex partitioning
✅ Scale is 100k+ messages/sec

Use RabbitMQ when:
✅ You need complex routing
✅ You need strong durability
✅ You need AMQP protocol
✅ You have mixed message patterns

Use SQS/SNS when:
✅ You're all-in on AWS
✅ You want fully managed
✅ Scale is unpredictable
✅ Cost is not the top priority

Summary

We've built a complete message queue system with:

user_messages_queue

ai_service_group

ai_to_user:{user_id}

Key Takeaways

1. Separation is Power: Separate input aggregation from output distribution
2. Per-User Streams: The simplest way to guarantee message isolation
3. Consumer Groups: Redis does the heavy lifting for work distribution
4. Zero Coordination: Workers don't need to know about each other
5. Dynamic Scaling: Add/remove workers without config changes
6. Production Ready: Built-in acknowledgment, pending tracking, and monitoring

When to Use This Pattern

Perfect for:

• Multi-tenant chat applications
• Task processing systems with multiple clients
• IoT data processing
• Microservices request/response patterns
• Any scenario with multiple producers and consumers

Not ideal for:

• Long-term data retention (use Kafka)
• Complex routing logic (use RabbitMQ)
• Extremely high scale (>1M messages/sec, use Kafka)

Next Steps

1. Clone the repository: github.com/rakeshbhugra/dynamic_consumers_for_redis_streams
2. Run the examples with 1, 2, 3 workers
3. Add your own users and watch the isolation
4. Replace the echo logic with actual AI processing
5. Add monitoring and alerting for production

The best way to learn is by running the code. Start with one worker and one user, then progressively add more. Watch how Redis automatically handles the distribution.

Your assignment: Implement this pattern in your next project that needs message queuing. Start simple with one worker, then scale up when needed.

Good luck building scalable systems!
